- Key features and advantages of ABS plastic:
Outstanding flame retardancy
UL94 V-0/V-1 certified (self-extinguishing within 3 seconds with no dripping of flaming particles).
High ignition temperature for hot wires (up to 850°C, meeting IEC 60695-2-12).
Mechanical properties
High impact strength (≥18 kJ/m², Izod notch), equivalent to standard ABS plastic.
Heat deflection temperature (HDT) of 85-100°C at 1.8 MPa, making it ideal for electrical enclosures. Halogen-free option (IEC 61249-2-21, <900 ppm Br/Cl). - Food contact application grade compliant with RoHS 2.0, REACH, and FDA standards.
2. Product specifications and grades
| range | Specifications | Target application |
|---|---|---|
| thickness | 0.5mm – 15mm (sheet) | Thin: PCB housing Thick: EV battery tray |
| Color Options | Black, white, gray, customized (RAL/Pantone) | Anti-lock Braking System |
| Emission reduction | Halogen-free (phosphorus/nitrogen) Halogenated (bromine) |
Halogen-free: medical devices Blade-like: industrial panels |
3. Popular industry applications
① Electronic appliances
- Power Adapter: UL94 V-0 ABS plastic housing prevents fire hazard in overload conditions.
Smart Home Hub: Non-grade halogen ensures low smoke density (<200 Ds) during combustion.
② Auto parts
- Electric vehicle battery housing: flame retardant ABS plastic, CTI＞600V (relative leakage index).
Among them: in compliance with FMVSS 302 (vertical burning speed <100mm/min)
③ Architecture and background
- Electrical conduit: ABS plastic tube meeting the glow wire 850°C standard (IEC 60695-2-11).
Public transport: protruding ABS frame (EN 45545-2 HL3 certified).
